Karatteristiċi
●Sa 11.3Gb/s links tad-data
●CWDM EML trasmettitur u riċevitur APD
●Sa 80km fuq 9/125µm SMF
●Hot-pluggable XFP footprint
●Supports Lineside u XFI loopback
●Duplex LC/UPC tip pluggable interface ottiku
●Metal egħluq, għal EMI aktar baxxi
●RoHS konformi u mingħajr ċomb
●Support Interface ta 'Monitoraġġ Dijanjostiku Diġitali
●Single +3.3V provvista ta 'enerġija
●No Reference Arloġġ meħtieġ
●Maximum konsum ta 'enerġija 3.5W
●Case temperatura operattiva
●Commercial: 0 ~ +70℃
Estiża: -10 ~ +80℃
Industrijali: -40 ~ +85℃
Applikazzjonijiet
10GBASE-ZR/ZW& 10G Ethernet
SDH STM64
Links Ottiċi Oħra
Informazzjoni dwar l-Ordni tan-Numru tal-Parti
PartNumber | Rata tad-Data (Gb/s) | Tul tal-mewġ (nm) | Distanza tat-Trażmissjoni (km) | Temperatura (oC) (Operating Case) |
HTXF-Cxx96ZC | 10.3125 | Refertorwavelengthselection | 80kmSMF | 0 ~ 70commercial |
HTXF-Cxx96ZE | 10.3125 | 80kmSMF | -10 ~ 80Estiż | |
HTXF-Cxx96ZI | 10.3125 | 80kmSMF | -40 ~ 85Industrijali |
Għażla tal-Wavelength: C-band λc Wavelength Guide Pin Descriptions
Tul tal-mewġ | x | ClaspColorCode | Tul tal-mewġ | x | ClaspColorCode |
1470nm | 47 | Griż | 1550nm | 55 | Isfar |
1490nm | 49 | Vjola | 1570nm | 57 | Oranġjo |
1510nm | 51 | Blu | 1590nm | 59 | aħmar |
1530nm | 53 | Aħdar | 1610nm | 61 | Kannella |
Karatteristiċi Ottiċi
Parametru | Simbolu | Min. | Tipiku | Max | Unità | Noti |
Trasmettitur | ||||||
Ottiku Wavelength | λ | λ-6.5 | λ-6.5 | nm | 1 | |
OpticalSpectralWidth | ∆λ | 1 | nm | |||
SidemodeSuppressionratio | SMSR | 30 | dB | |||
Enerġija Ottika Medja | PAVG | 0 | 5 | dBm | ||
OpticalExtinctionRatio | ER | 9 | dB | |||
Penali tat-TrasmettituruDispersjoni | TDP | 3 | dB | |||
Potenza Medja ta' Tnedija tat-trasmettitur OFF | POFF | -30 | dBm | |||
TransmitterEyeMask | Konformi mal-IEEE802.3ae | |||||
Riċevitur | ||||||
CenterWavelength | λC | 1270 | 1610 | nm | ||
Sensittività tar-Riċevitur(Qawwa Medja) | Sen. | -24 | dBm | 2 | ||
InputSaturationPower (tagħbija żejda) | Psat | -6 | dBm | |||
LOSAssert | LOSA | -37 | dBm | |||
LOSDe-jasserixxu | LOSD | -27 | dBm | |||
RiċeviturReflectance | Rrx | -27 | dB | |||
LOSIsteresi | LOSH | 0.5 | dB | |||
